MAXCREAM Series
MAXCREAM separators are centrifugal separators configured as a concentrator(skimmer) for efficient, fast and hygienic separation of fat from milk. They can be adjusted to separate standard or high concentrations of cream in milk or to completely separate the fat from the whey.
MAXCREAM separators processes the milk gently with the least possible fat residues in the content of skimmed milk under ideal process conditions. When separating the cream from the milk, it allows you to adjust the cream concentration by means of counter pressure valves located at the phase outlets of the separator. MAXCREAM separators can achieve a wide range of cream concentration between 40% and 65% values. You can easily and precisely adjust the cream concentration using the MILKOTUNE standardization unit as well as the counter-pressure valves. Due to their high separation efficiency, they are effective in cleaning of contaminating solid particles as well as skimming. Thanks to its fast and effective discharge system, it provides solid discharge with minimum product content.
PRODUCT MODELS
*HAUS, reserves the right to modify the specifications herein at anytime without prior notice.
PRODUCT SLICE
MAXCREAM separators are centrifugal separators configured as a concentrator(skimmer) for efficient, fast and hygienic separation of fat from milk. They can be adjusted to separate standard or high concentrations of cream in milk or to completely separate the fat from the whey.
MAXCREAM separators processes the milk gently with the least possible fat residues in the content of skimmed milk under ideal process conditions. When separating the cream from the milk, it allows you to adjust the cream concentration by means of counter pressure valves located at the phase outlets of the separator. MAXCREAM separators can achieve a wide range of cream concentration between 40% and 65% values. You can easily and precisely adjust the cream concentration using the MILKOTUNE standardization unit as well as the counter-pressure valves. Due to their high separation efficiency, they are effective in cleaning of contaminating solid particles as well as skimming. Thanks to its fast and effective discharge system, it provides solid discharge with minimum product content.
High quality stainless steel design
Special design submerged feed pipe
Ready for Cleaning In Place(CIP)
Fast and effective discharge system
Hygienic Design
High separation efficiency
It can be delivered as a skid to ready to operate and easy to put in place
PRODUCT MODELS
TECHNICAL SPECS | |
INSTALLED MOTOR POWER | 11 kW |
DIMENSIONS (Length * Width, Height) | 1500x1830, 1940 mm |
WEIGHT | 1300 kg |
TECHNICAL SPECS | |
INSTALLED MOTOR POWER | 15 kW |
DIMENSIONS (Length * Width, Height) | 1500x1830, 1940 mm |
WEIGHT | 1300 kg |
TECHNICAL SPECS | |
INSTALLED MOTOR POWER | 18,5 kW |
DIMENSIONS (Length * Width, Height) | 1500x1830, 1940 mm |
WEIGHT | 1300 kg |
TECHNICAL SPECS | |
INSTALLED MOTOR POWER | 30 kW |
DIMENSIONS (Length * Width, Height) | 1730x2400, 2090 mm |
WEIGHT | 1600 kg |
TECHNICAL SPECS | |
INSTALLED MOTOR POWER | 45 kW |
DIMENSIONS (Length * Width, Height) | 1940x1210, 2350 mm |
WEIGHT | 2650 kg |
PRODUCT SLICE
APPLICATIONS OF THE PRODUCT
