Food Applications · F Series
The DDF Series is a decanter centrifuge: horizontal rotating bowl, 2-phase or 3-phase configuration, continuous discharging of sludge through scrolling conveyor, dual-drive type, variable differential speed.
The DDF series has been designed by HAUS specifically for the food and bevarage industry. The duty is the processing of Fruits or Vegetables to produce beverages, and the treatment of the by-products. DDF series aims to reduce the solid content of the liquid mixture (juice clarification) or dewatering the solid mixture (pulp concentration).
PRODUCT MODELS
*HAUS, reserves the right to modify the specifications herein at anytime without prior notice.
PRODUCT SLICE
The DDF Series is a decanter centrifuge: horizontal rotating bowl, 2-phase or 3-phase configuration, continuous discharging of sludge through scrolling conveyor, dual-drive type, variable differential speed.
The DDF series has been designed by HAUS specifically for the food and bevarage industry. The duty is the processing of Fruits or Vegetables to produce beverages, and the treatment of the by-products. DDF series aims to reduce the solid content of the liquid mixture (juice clarification) or dewatering the solid mixture (pulp concentration).
Maximum Performence
High G Force: a bowl, rotating at very high speed
Flexible Configuration
Multiple choice of material of construction, wear protection, motor power, gearbox torque
Touch Panel
PLC with HMI: to set different automatic mode, to adjust the sludge dryness and other operational parameters, to monitor alarms
High Hygiene
Food grade material and lubricants, grooved inner bowl surface, polished contact surfaces to avoid product deposit
Product Based Performance
Variable Solid Conveying Speed: to handle different solid quantity with desired dryness
Dual Drive
A main motor moving the bowl , and a secondary motor moving the conveyor, both driven by Frequency Converter (VFD) and linked by a high torque gearbox without friction clutch
PRODUCT MODELS
DDF 2342 / DDF 2343 is used in the processing of fruits or vegetables to produce beverages, and the treatment of the by-products.
| TECHNICAL SPECS | |
| INSTALLED MOTOR POWER | 9,7 kW / 11,5 kW |
| DIMENSIONS (Length * Width, Height) | 2360x830, 1030 mm |
| WEIGHT | 900 kg |
DDF 3532 / DDF 3533 is used in the processing of fruits or vegetables to produce beverages, and the treatment of the by-products.
| TECHNICAL SPECS | |
| INSTALLED MOTOR POWER | 19 kW / 24 kW |
| DIMENSIONS (Length * Width, Height) | 3210x890, 1090 mm |
| WEIGHT | 1750 kg |
DDF 3542 / DDF 3543 is used in the processing of fruits or vegetables to produce beverages, and the treatment of the by-products.
| TECHNICAL SPECS | |
| INSTALLED MOTOR POWER | 24 kW / 29,5 kW |
| DIMENSIONS (Length * Width, Height) | 3930x1000, 1115 mm |
| WEIGHT | 1650 kg |
DDF 4042 / DDF 4043 is used in the processing of fruits or vegetables to produce beverages, and the treatment of the by-products.
| TECHNICAL SPECS | |
| INSTALLED MOTOR POWER | 41 kW / 45 kW |
| DIMENSIONS (Length * Width, Height) | 3550x885, 1081 mm |
| WEIGHT | 2200 kg |
DDF 4742 / DDF 4743 is used in the processing of fruits or vegetables to produce beverages, and the treatment of the by-products.
| TECHNICAL SPECS | |
| INSTALLED MOTOR POWER | 52 kW / 63,5 kW |
| DIMENSIONS (Length * Width, Height) | 4700x1370, 1120 mm |
| WEIGHT | 4200 kg |
DDF 5342 / DDF 5343 is used in the processing of fruits or vegetables to produce beverages, and the treatment of the by-products.
| TECHNICAL SPECS | |
| INSTALLED MOTOR POWER | 70 kW / 105 kW |
| DIMENSIONS (Length * Width, Height) | 5415x1565, 1510 mm |
| WEIGHT | 6200 kg |
DDF 6542 / DDF 6543 is used in the processing of fruits or vegetables to produce beverages, and the treatment of the by-products.
| TECHNICAL SPECS | |
| INSTALLED MOTOR POWER | 112 kW / 147 kW |
| DIMENSIONS (Length * Width, Height) | 5903x2130, 1495 mm |
| WEIGHT | 9700 kg |
DDF 8242 / DDF 8243 is used in the processing of fruits or vegetables to pro
| TECHNICAL SPECS | |
| INSTALLED MOTOR POWER | 169 kW / 205 kW |
| DIMENSIONS (Length * Width, Height) | 6131x2463, 2463 mm |
| WEIGHT | 15800 kg |
